eCC110-A01
The eCC110-A01 is a cutting-edge solution in industrial computing, powered by the advanced Intel Celeron® N97 Quad Core processor. This powerhouse delivers outstanding computing and graphics capabilities, ensuring your operations run smoothly and efficiently.
Overview
The eCC110-A01, powered by the latest Intel Celeron® N97 Quad Core processor, delivers exceptional computing and graphics performance. It offers up to 16GB of DDR5 memory and supports various storage options like M.2 and Mini PCIe.
With 3 x 2.5GbE TSN LAN ports and 4 x COM ports, it integrates seamlessly into factory automation, network, and communication applications. Optional Wi-Fi and 5G/4G/LTE modules enhance connectivity.
Designed for tough environments, it operates efficiently in temperatures from -40°C to 70°C.
Downloads
Key features
- Onboard Intel Celeron® Processor N97 quad-core 2.0GHz
- 2 x Display output, 1 x HDMI and 1 x DP port
- 3 x Intel® I226-IT 2.5GbE TSN LAN port; supports WoL, teaming and PXE
- Storage supports mSATA and M.2 SATA & PCIe x2 modules
- 1 x Mini PCIe Wi-Fi/LTE wireless module
- 2 x USB 3.2
- 2 x USB 2.0
- 2 x DB9 for RS-232/422/485
- 2 x DB9 for RS-232
- Support -40°C~70°C extended operating temperature
- Support 9~30V DC input; supports AT/ATX power mode
Choose your product
Ordering Information
| Part Number and Description | |
|---|---|
| 10J00011002X0 | Intel Celeron® N97 Quad Core Factory Automation Fanless System |
Validated technical specifications of our products are exclusively available in PDF documents named "Datasheet," which can be downloaded from the product page on our website.
